Chipset: Intel H410
Sockets Supported: LGA1200
Supported CPU: 10th Generation Intel Core i9/ i7/ i5/ i3/ Pentium/ Celeron Processors
Generation: 10th
Memory Slot: 2
Memory Max.: 64GB
Brand | Gigabyte |
Model | Gigabyte H410M H |
Body Color | Black |
Chipset Brand | Intel |
Chipset | Intel H410 |
Sockets Supported | LGA1200 |
Built-in Processor | No |
Supported CPU | 10th Generation Intel Core i9/ i7/ i5/ i3/ Pentium/ Celeron Processors |
Generation | 10th |
Memory Type | DDR4 |
Memory MHz | Intel Core i9/i7 3200/ 2933/ 2666/ 2400/ 2133MHz, Intel Core i5/i3/Pentium/Celeron 2666/ 2400/ 2133MHz) |
Memory Channel | Dual |
Memory Slot | 2 |
Memory Max. | 64GB |
Optane Memory Support | Yes |
Storage Interface | 6.0Gb/s |
M.2/SSD Expansion Slot | 1 |
M.2/SSD Expansion Slot Details | 1 x M.2 Socket 3 (Type 2242/2260/2280 SATA and PCIe x2 SSD) |
Graphics | Integrated |
Graphics Chipset | Intel HD Graphics support |
PCI Express Slot | 1 x PCI Express x16 slot, running at x16, 2 x PCI Express x1 |
Audio Chipset | Realtek ALC887 |
Audio Channel | 2/4/5.1/7.1 |
LAN Chipset | Realtek GbE LAN |
LAN Speed (Mbps) | 100/1000 |
WiFi | No |
Bluetooth | No |
USB Port | 2 x USB 3.2 Gen 1, 4 x USB 2.0/1.1 |
VGA Port | 1 |
DVI Port | No |
HDMI Port | 1 |
DisplayPort (DP) | No |
SATA Port | 4 x SATA |
Thunderbolt | No |
TPM Port | Yes |
CrossFire Support | No |
Sli Support | No |
RGB Support | RGB |
RGB Connector | 1 x RGB LED strip header |
Approx. Power Consumption | 65W |
Form Factor | Micro-ATX |
BIOS Type | 1 x 128 Mbit flash |
BIOS Model | AMI UEFI BIOS |
Supported Operating System | Windows 10 |
Warranty Details | 3 year |
Feature | Intel H410 Ultra Durable Motherboard with GIGABYTE 8118 Gaming LAN, Anti-Sulfur Resistor, Smart Fan 5,Supports 10th Gen Inte Core Processors,Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs,8-Channel HD Audio with High Quality Audio Capacitors GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management,Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP,GIGABYTE APP Center, Simple and Easy Use,Anti-Sulfur Resistors Design |
Others | 1 x CPU fan header, 1 x system fan header, 4 x SATA 6Gb/s connectors, 1 x M.2 Socket 3 connector, 1 x front panel header, 1 x front panel audio header |
Country Of Origin | Taiwan |
Made in/ Assemble | China |
