Chipset: AMD B450
Sockets Supported: AM4
Supported CPU: 1st, 2nd and 3rd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics/ Athlon with Radeon Vega Graphics Desktop Processors
Generation: Not Applicable
Memory Slot: 4
Memory Max.: 128GB
| Brand | Gigabyte |
| Model | Gigabyte B450M DS3H V2 |
| Body Color | Black |
| Chipset Brand | AMD |
| Chipset | AMD B450 |
| Sockets Supported | AM4 |
| Built-in Processor | No |
| Supported CPU | 1st, 2nd and 3rd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics/ Athlon with Radeon Vega Graphics Desktop Processors |
| Generation | Not Applicable |
| Memory Type | DDR4 |
| Memory MHz | 3600(O.C.) / 3466(O.C.) / 3200(O.C.) / 2933 / 2667 / 2400 / 2133 MHz |
| Memory Channel | Dual |
| Memory Slot | 4 |
| Memory Max. | 128GB |
| Optane Memory Support | No |
| Storage Interface | 6.0Gb/s |
| M.2/SSD Expansion Slot | 1 |
| M.2/SSD Expansion Slot Details | 1 x M.2 (Type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD) |
| Graphics | Integrated |
| Graphics Chipset | Integrated With Processor |
| PCI Express Slot | 2 x PCI Express x 16, 1 x PCI Express x 1 |
| Audio Chipset | Realtek ALC887 codec |
| Audio Channel | 2/4/5.1/7.1 |
| LAN Chipset | Realtek GbE LAN chip |
| LAN Speed (Mbps) | 10/100/1000 Mbps |
| WiFi | No |
| USB Port | 4 x USB2.0/1.1, 4 x USB3.1 Gen 1 |
| VGA Port | No |
| DVI Port | 1 |
| HDMI Port | 1 |
| DisplayPort (DP) | No |
| SATA Port | 4 x SATA |
| Thunderbolt | No |
| TPM Port | Yes |
| COM Port | No |
| Sli Support | No |
| RGB Support | RGB |
| RGB Connector | 1 x RGB LED strip header |
| Approx. Power Consumption | 60W |
| Form Factor | Micro-ATX |
| CrossFire Support | Yes |
| BIOS Type | 1 x 128 Mbit flash |
| BIOS Model | AMI UEFI BIOS |
| Supported Operating System | Windows 10 |
| Warranty Details | 3 year |
| Feature | Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Feature Digital VRM Solution with Low RDS(on) MOSFETs HDMI, DVI-D Ports for Multiple Display Ultra-Fast PCIe Gen3 x4 M.2 with PCIe NVMe & SATA mode support High Quality Audio Capacitors and Audio Noise Guard with LED Trace Path Lighting GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management RGB Fusion supports RGB LED Strips in 7-Colors Smart Fan 5 Features 5 Temperature Sensors and 2 Hybrid Fan Headers with FAN STOP |
| Others | 1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector, 1 x CPU fan header, 1 x system fan header, 1 x M.2 Socket 3 connector, 1 x front panel header, 1 x front panel audio header, 1 x S/PDIF Out header |
| Country Of Origin | Taiwan |
| Made in/ Assemble | China |
